ATP3334 Spectrometer is newly designed ultra thin, uncooled, ultra high resolution miniature spectrometers developed by Optosky. ATP3334 Spectrometer are M-type optical path structures, which have extraordinary ultra-high resolution. Uncooled 4096 pixels at the same time, it uses the linear array detector, reached the acme of the ultra high resolution, high resolution can reach <0.04 nm, suitable for all kinds of applications, high resolution and high reliability, ultra-high speed, low cost, high cost performance and other characteristics, can adapt to the online test uses a variety of environments such as micro Spectrometer.
ATP3334 spectrometer is uncooled, which greatly reduces the dark current and noise , improves the dynamic range and signal-to-noise ratio, and improves the environmental adaptability of the Spectrometer.
ATP3334 Spectrometer can receive SMA905 fiber input light or free space light, and output the spectral data obtained through USB2.0 or UART port.
ATP3334 Spectrometer has free SDK for customers self-developed, Optosky support C++, C#, Labview and Linux system SDK, which is very convenient for OEM customers to design solutions.
Feature
- M-shape, high resolution
- Wavelength range: 200-1100 nm
- Resolution: 0.05~ 2 nm
- Optical path: M-shape C-T
- Detector: 2048/4096 pixel
- Integration time: 0.2ms ~ 65s
- Power supply: DC 5V power supply
- ADC：16 bit
- Output：USB Type-C
- 20-pin expansion interface
